Classic vintage pendant luminaire
Professional ARVENQ solution based on a specialized OEM platform, configured under a European premium lighting brand for outdoor and infrastructure projects. Final options depend on the selected power, optics, driver, control and certification.
- Power: 30–70 W
- Efficacy: Up to 120 lm/W
- Protection: IP66 · IK08
- CCT: Depending on configuration
- Control: 1–10 V, time scheduling and smart functions depending on driver
Description
Classic pendant LED luminaire for urban and heritage environments.
Decorative design with aluminium housing, Type II Medium optic and serviceable driver/SPD.
Technical data
| ARVENQ model | AVQ-GD080-C1 |
| Power | 30–70 W |
| Efficacy | Up to 120 lm/W |
| Input voltage | 100–240/277 VAC, 50/60 Hz |
| Power factor | >0,95 |
| IP rating | IP66 |
| IK rating | IK08 |
| CCT | Depending on configuration |
| CRI | Depending on configuration |
| Material / construction | Housing de aluminium ADC12 fundido a presión |
| Surge protection | 10 kV standard; 20 kV on request |
| Operating temperature | Depending on configuration |
| Optics / distribution | Type II Medium |
| Mounting | Mounting superior/pendant depending on conjunto |
| Service life | According to documented configuration |
| Warranty | Minimum 10 years |
| Control | 1–10 V, time scheduling and smart functions depending on driver |
| Certifications / tests | CE, RoHS, IP66, IK08, LM80, TM-21 and IEC62471 |
Optic
Distribution: Type II Medium
Mounting: Mounting superior/pendant depending on conjunto
IES/LDT photometric files are published or supplied only for the exact selected configuration.
Videos
Videos are shown only when validated technical material exists for this model or configuration. Generic videos are not presented as if they belonged to the product.
Downloads
The ARVENQ technical data sheet, manual, IES/LDT files, certificates and CAD/BIM files are enabled only when they correspond to the exact configuration offered. Draft files or documents from another variant are not published.
Application
Vías urbanas, zonas residenciales, aceras, parking areas, puentes and entornos históricos.
FAQ
What power range does this model have?
30–70 W.
What optics and mounting options are available?
Type II Medium. Mounting: Mounting superior/pendant depending on conjunto.
Does it support dimming or smart control?
1–10 V, time scheduling and smart functions depending on driver.
Can IES/LDT files be requested?
Yes. They are supplied for the exact selected photometric configuration.
Are certifications the same for every variant?
Not necessarily. Applicable documentation is confirmed for the power, driver, optics and final supplied configuration.
Related products
Certifications and tests
CE, RoHS, IP66, IK08, LM80, TM-21 and IEC62471
Certifications and tests are linked to the specific technical configuration. ARVENQ does not attribute to one variant certificates that apply only to another version of the platform.
Request solutions and quotations
We can assist with luminaire selection, lighting design, technical support, project documentation and product configuration.
