Smooth-body industrial high bay for food processing
Professional ARVENQ solution based on a specialized OEM platform, configured under a European premium lighting brand for outdoor and infrastructure projects. Final options depend on the selected power, optics, driver, control and certification.
- Power: Up to 150 W
- Efficacy: 130–170 lm/W
- Protection: IP66 · IK08 / IK10
- CCT: 3000 / 4000 / 5000 / 5700 K
- Control: DALI, 1–10 V, motion sensor, Zigbee or LoRa
Description
Smooth-body high bay for food-processing facilities and spaces requiring easy cleaning.
Housing without exposed fins, symmetric optics and Class I/II options.
Technical data
| ARVENQ model | AVQ-HB150-F |
| Power | Up to 150 W |
| Efficacy | 130–170 lm/W |
| Input voltage | 100–240/277 VAC, 50/60 Hz |
| Power factor | >0,95 |
| IP rating | IP66 |
| IK rating | IK08 / IK10 |
| CCT | 3000 / 4000 / 5000 / 5700 K |
| CRI | Ra >70; Ra >80 depending on configuration |
| Material / construction | Housing lisa de die-cast aluminium, diseñada for facilitar limpieza |
| Surge protection | 10 kV standard; 20 kV on request |
| Operating temperature | -40 °C to +50 °C |
| Optics / distribution | 60° / 90° / 120° |
| Mounting | Hook / loop |
| Service life | According to documented configuration |
| Warranty | Minimum 10 years |
| Control | DALI, 1–10 V, motion sensor, Zigbee or LoRa |
| Certifications / tests | ENEC, CE, CB, RoHS, LM79, LM80, TM-21, ISTMT, IEC62471/62788 and IEC61643-11 depending on configuration |
Optic
Distribution: 60° / 90° / 120°
Mounting: Hook / loop
IES/LDT photometric files are published or supplied only for the exact selected configuration.
Videos
Videos are shown only when validated technical material exists for this model or configuration. Generic videos are not presented as if they belonged to the product.
Downloads
The ARVENQ technical data sheet, manual, IES/LDT files, certificates and CAD/BIM files are enabled only when they correspond to the exact configuration offered. Draft files or documents from another variant are not published.
Application
Food processing, production, warehouses and areas where easy surface cleaning is prioritized.
FAQ
What power range does this model have?
Up to 150 W.
What optics and mounting options are available?
60° / 90° / 120°. Mounting: Hook / loop.
Does it support dimming or smart control?
DALI, 1–10 V, motion sensor, Zigbee or LoRa.
Can IES/LDT files be requested?
Yes. They are supplied for the exact selected photometric configuration.
Are certifications the same for every variant?
Not necessarily. Applicable documentation is confirmed for the power, driver, optics and final supplied configuration.
Related products
Certifications and tests
ENEC, CE, CB, RoHS, LM79, LM80, TM-21, ISTMT, IEC62471/62788 and IEC61643-11 depending on configuration
Certifications and tests are linked to the specific technical configuration. ARVENQ does not attribute to one variant certificates that apply only to another version of the platform.
