Compact split-type solar luminaire
Professional ARVENQ solution based on a specialized OEM platform, configured under a European premium lighting brand for outdoor and infrastructure projects. Final options depend on the selected power, optics, driver, control and certification.
- Power: 20–60 W
- Efficacy: Up to 160 lm/W
- Protection: IP66 · IK10
- CCT: 3000 / 4000 / 5000 / 5700 K
- Control: Motion sensor/PIR, time scheduling and daylight sensor
Description
Compact split solar system for local roads, paths and lower-height areas.
Flexible architecture with MPPT controller and a choice of different LED heads and optical distributions.
Technical data
| ARVENQ model | AVQ-SL060-SP |
| Power | 20–60 W |
| Efficacy | Up to 160 lm/W |
| Input voltage | DC 12/24 V |
| Power factor | Not applicable en alimentación DC del sistema solar |
| IP rating | IP66 |
| IK rating | IK10 |
| CCT | 3000 / 4000 / 5000 / 5700 K |
| CRI | Ra >70; Ra >80 depending on configuration |
| Material / construction | Head LED de aluminium, monocrystalline panel and sistema de almacenamiento/control depending on platform |
| Surge protection | Integrated protections en controller solar |
| Operating temperature | -40 °C to +50 °C |
| Optics / distribution | Type I, II, III and V |
| Mounting | Post-top or entrada lateral |
| Service life | Depending on configuration de batería and LED |
| Battery | Customizable |
| Solar panel | Monocrystalline, capacidad customizable |
| Warranty | Minimum 10 years |
| Control | Motion sensor/PIR, time scheduling and daylight sensor |
| Certifications / tests | CE, RoHS, LM80 and TM-21 depending on configuration |
Optic
Distribution: Type I, II, III and V
Mounting: Post-top or entrada lateral
IES/LDT photometric files are published or supplied only for the exact selected configuration.
Videos
Videos are shown only when validated technical material exists for this model or configuration. Generic videos are not presented as if they belonged to the product.
Downloads
The ARVENQ technical data sheet, manual, IES/LDT files, certificates and CAD/BIM files are enabled only when they correspond to the exact configuration offered. Draft files or documents from another variant are not published.
Application
Streets, roads, parks, parking areas and locations without a stable electrical grid.
FAQ
What power range does this model have?
20–60 W.
What optics and mounting options are available?
Type I, II, III and V. Mounting: Post-top or entrada lateral.
Does it support dimming or smart control?
Motion sensor/PIR, time scheduling and daylight sensor.
Can IES/LDT files be requested?
Yes. They are supplied for the exact selected photometric configuration.
Are certifications the same for every variant?
Not necessarily. Applicable documentation is confirmed for the power, driver, optics and final supplied configuration.
Related products
Certifications and tests
CE, RoHS, LM80 and TM-21 depending on configuration
Certifications and tests are linked to the specific technical configuration. ARVENQ does not attribute to one variant certificates that apply only to another version of the platform.
